Product Details
Power
9-12kw
Application
Industrial Use
Warranty
1year
Country of Origin
India
Air Blower Count
2
Pressure Range
0-10 kg
Maximum Temperature
30 Degree
Volume
5-7 KL
Oxygenate Capability
30-35 m3
Hydraulic Retention Time
6-8 Hr.
Hopper Slope
45-55 Degree
Feed Flow Rate
0.75 m3/hr.
Water Pump Power
1.5 kW
Overall Dimensions
11X5 Mtr.
Approximate Power Consumption
15 kW
Air Flow Rate
30-40 m3/hr @ 0.4 kg/cm2
Air Blower Flow
30 - 40
Sludge Holding Chamber Volume
7 KL
Equalization Chamber Volume
10 KL
Aeration Chamber Volume
8-10 KL
Air Blower Power
1.5 kW
Capacity (KLD)
15 KLD
15 KLD MBBR Based sewage treatment plant. 1. Bar Screen 2. MBBR Media 3. Secondry Settling Media 4. Chlorine Dosing System 5. Multi-grade Sand Filter 6. Activated Carbon Filter 7. Sewage transfer pump 8. Sludge Recirculation/Transfer pump 9. Filter Feed Pump 10. Air Blower 11. Air Diffuser 12. Sludge Feed Pump 13. Filter Press 14. Electric Control Panel & etc...
